| Onderdeel nummer | G215HAN01.201 |
| Merk | AUO |
| Maat | 21.5 |
| Sollicitatie | Industrial Medical I |
| Oplossing | 1920×1080 |
| Samenstelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleuren | 16.7M |
| Tegenlicht | 12S4P |
| Koppel | LVDS |
| paneel merk | AUO |
| paneelmodel | G215HAN01.201 |
| paneel grootte | 21.5" |
| paneel type | a-Si TFT-LCD, LCM |
| oplossing | 1920(RGB)×1080, FHD, 102PPI |
| pixel formaat | RGB Vertical Stripe |
| weergavegebied | 476.064(W)×267.786(H) mm |
| omlijsting openen | 479.8(W)×271.3(H) mm |
| omtrek grootte | 497.6(W)×292.2(H) ×11(D) mm |
| oppervlak | Antiglare, Hard coating (3H) |
| helderheid | 300 cd/m² (Typ.) |
| contrast ratio | 1000:1 (Typ.) (TM) |
| kijk hoek | 89/89/89/89 (Typ.)(CR≥10) |
| weergavemodus | AHVA, Normally Black, Transmissive |
| beste zicht op | Symmetry |
| reactietijd | 12/10 (Typ.)(Tr/Td) |
| kleuren weergeven | 16.7M 99% sRGB |
| soort lamp | 12S4P WLED , 50K hours , Without Driver |
| frequentie | 60Hz |
| touch screen | Without |
| paneel gewicht | 1.74Kgs (Typ.) |
| sollicitatie | Industrial Medical Imaging |
| signaal interface | LVDS (2 ch, 8-bit) , 30 pins Connector |
| ingangsspanning | 5.0V (Typ.) |
| omgeving | Operating Temp.: 0 ~ 60 °C ; Storage Temp.: -20 ~ 60 °C |
| CLAA215FA04 | CPT | 21.5 | 1920×1080 |
| HM215WU3-100 | BOE | 21.5 | 1920×1080 |
| HM215WU3-101 | BOE | 21.5 | 1920×1080 |
| LC215EUE-TEA1 | LG Display | 21.5 | 1920×1080 |
| LM215DB-T02 | PANDA | 21.5 | 1920×1080 |
| LM215WF2-SLD1 | LG Display | 21.5 | 1920×1080 |
| LM215WF3-SLC1 | LG Display | 21.5 | 1920×1080 |
| LM215WF4-TLE1 | LG Display | 21.5 | 1920×1080 |
| LM215WF4-TRA1 | LG Display | 21.5 | 1920×1080 |
| M215HGE-P02 | Innolux | 21.5 | 1920×1080 |
