| Onderdeel nummer | G185XW01 V201 |
| Merk | AUO |
| Maat | 18.5 |
| Sollicitatie | Industrial |
| Oplossing | 1366×768 |
| Samenstelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleuren | 16.7M |
| Tegenlicht | WLED |
| Koppel | LVDS |
| paneel merk | AUO |
| paneelmodel | G185XW01 V201 |
| paneel grootte | 18.5" |
| paneel type | a-Si TFT-LCD, LCM |
| oplossing | 1366(RGB)×768, WXGA, 84PPI |
| pixel formaat | RGB Vertical Stripe |
| weergavegebied | 409.8(W)×230.4(H) mm |
| omlijsting openen | 413.4(W)×234.0(H) mm |
| omtrek grootte | 430.4(W)×254.7(H) mm |
| oppervlak | Antiglare, Hard coating (3H) |
| helderheid | 450 cd/m² (Typ.) |
| contrast ratio | 1000:1 (Typ.) (TM) |
| kijk hoek | 85/85/80/80 (Typ.)(CR≥10) |
| weergavemodus | TN, Normally White, Transmissive |
| beste zicht op | - |
| reactietijd | 3.5/1.5 (Typ.)(Tr/Td) |
| kleuren weergeven | 16.7M 70% NTSC |
| soort lamp | WLED , 50K hours , With LED Driver |
| frequentie | 60Hz |
| touch screen | Without |
| paneel gewicht | 1.44Kgs (Max.) |
| sollicitatie | Industrial |
| signaal interface | LVDS (1 ch, 8-bit) , 30 pins Connector |
| ingangsspanning | 5.0V (Typ.) |
| omgeving | Operating Temp.: 0 ~ 60 °C ; Storage Temp.: -20 ~ 60 °C |
| G185XW01 V1 | AUO | 18.5 | 1366×768 |
| G185XW01 V2 | AUO | 18.5 | 1366×768 |
| HM185WX1-400 | BOE | 18.5 | 1366×768 |
| LC185EXE-TEA1 | LG Display | 18.5 | 1366×768 |
| LC190WH1-TLC1 | LG Display | 18.5 | 1366×768 |
| LTA185AT01 | Samsung | 18.5 | 1366×768 |
| LTM185AT04 | Samsung | 18.5 | 1366×768 |
| M185XW01 V3 | AUO | 18.5 | 1366×768 |
| M185XW01 V4 | AUO | 18.5 | 1366×768 |
| M185XW01 V6 | AUO | 18.5 | 1366×768 |
