| Onderdeel nummer | G170HAN01.0 |
| Merk | AUO |
| Maat | 17.0 |
| Sollicitatie | Industrial |
| Oplossing | 1920×1920 |
| Samenstelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleuren | 16.7M |
| Tegenlicht | 9S6P |
| Koppel | |
| paneel merk | AUO |
| paneel grootte | 17.0" |
| oplossing | 1920(RGB)×1920, 159PPI |
| weergavegebied | 305.28(W)×305.28(H) mm |
| omtrek grootte | 325.01(W)×319.33(H) ×12.2(D) mm |
| helderheid | 600 cd/m² (Typ.) |
| kijk hoek | 89/89/89/89 (Typ.)(CR≥10) |
| beste zicht op | Symmetry |
| kleuren weergeven | 16.7M 72% NTSC |
| frequentie | 60Hz |
| gewicht | 1.20Kgs (Max.) |
| paneelmodel | G170HAN01.0 |
| paneel type | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| omlijsting openen | - |
| oppervlak | Antiglare, Hard coating (3H) |
| contrast ratio | 1000:1 (Typ.) (TM) |
| weergavemodus | AHVA, Normally Black, Transmissive |
| reactietijd | 13/12 (Typ.)(Tr/Td) |
| soort lamp | 9S6P WLED , 50K hours , With LED Driver |
| touch screen | Without |
| sollicitatie | Industrial |
