| Onderdeel nummer | G170ETN03.1 |
| Merk | AUO |
| Maat | 17.0 |
| Sollicitatie | Industrial |
| Oplossing | 1280×1024 |
| Samenstelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleuren | 16.7M |
| Tegenlicht | WLED |
| Koppel | LVDS |
| merk | AUO |
| model | G170ETN03.1 |
| diagonale maat | 17.0 inch |
| type | a-Si TFT-LCD, LCM |
| pixel formaat | 1280(RGB)×1024 [SXGA] 96PPI |
| configuratie | RGB Vertical Stripe |
| actief gebied | 337.92(H)×270.336(V) mm |
| omtrek afm. | 358.5(H)×296.5(V) ×10.8(D) mm |
| bezel gebied | 341.7(H)×274.1(V) mm |
| behandeling | Antiglare, Hard coating (3H) |
| luminantie | 400 cd/m² (Typ.) |
| contrast ratio | 1000:1 (Typ.) (TM) |
| richting bekijken | - |
| reactietijd | 3.8/1.2 (Typ.)(Tr/Td) |
| kijk hoek | 85/85/80/80 (Typ.)(CR≥10) |
| bedrijfsmodus | TN, Normally White, Transmissive |
| ondersteunende kleur | 16.7M 72% NTSC |
| lichtbron | WLED [9S4P] , 30K hours , W/O Driver |
| gewicht | 1.27Kgs (Typ.) |
| ontworpen voor | Industrial |
| frame rate | 60Hz |
| aanraakpaneel | Without |
| interface-type | LVDS (2 ch, 8-bit) , 30 pins Connector |
| stroomvoorziening | 5.0V (Typ.) |
| omgeving | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
