| Onderdeel nummer | G156XW01 V4 |
| Merk | AUO |
| Maat | 15.6 |
| Sollicitatie | Industrial |
| Oplossing | 1366×768 |
| Samenstelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 500:1 |
| Kleuren | 16.2M |
| Tegenlicht | WLED |
| Koppel | |
| paneel merk | AUO |
| paneel grootte | 15.6" |
| oplossing | 1366(RGB)×768, WXGA, 100PPI |
| weergavegebied | 344.232(W)×193.536(H) mm |
| omtrek grootte | 363.8(W)×215.9(H) mm |
| helderheid | 500 cd/m² (Typ.) |
| kijk hoek | 85/85/80/80 (Typ.)(CR≥10) |
| beste zicht op | - |
| kleuren weergeven | 16.2M 62% NTSC |
| frequentie | 60Hz |
| gewicht | 860±40g |
| paneelmodel | G156XW01 V4 |
| paneel type | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| omlijsting openen | 347.54(W)×196.83(H) mm |
| oppervlak | Antiglare, Hard coating (3H) |
| contrast ratio | 500:1 (Typ.) (TM) |
| weergavemodus | TN, Normally White, Transmissive |
| reactietijd | 6/2 (Typ.)(Tr/Td) |
| soort lamp | WLED , 50K hours , With LED Driver |
| touch screen | Without |
| sollicitatie | Industrial |
| G156XW01 V0 | AUO | 15.6 | 1366×768 |
| G156XW01 V1 | AUO | 15.6 | 1366×768 |
| G156XW01 V3 | AUO | 15.6 | 1366×768 |
| LP156WF6-SPH3 | LG Display | 15.6 | 1920×1080 |
| LP156WH1-TLC1 | LG Display | 15.6 | 1366×768 |
| LTN156AT35-W02 | Samsung | 15.6 | 1366×768 |
| M156B3-L01 | Innolux | 15.6 | 1366×768 |
| N156B6-L0A | Innolux | 15.6 | 1366×768 |
| N156O6-L01 | Innolux | 15.6 | 1600×900 |
| TMS156WX1-02TC | Tianma | 15.6 | 1366×768 |
