| Onderdeel nummer | G156HAN02.1 |
| Merk | AUO |
| Maat | 15.6 |
| Sollicitatie | Industrial Medical I |
| Oplossing | 1920×1080 |
| Samenstelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 1000:1 |
| Kleuren | 16.7M |
| Tegenlicht | WLED |
| Koppel | LVDS |
| fabrikant | AUO |
| scherm grootte | 15.6 inch |
| pixel nummer | 1920(RGB)×1080 (FHD) 141PPI |
| actief gebied (mm) | 344.16 × 193.59 (H×V) |
| bezel gebied (mm) | 347.06 × 196.49 (H×V) |
| luminantie | 500 cd/m² (Typ.) |
| kijk hoek | 89/89/89/89 (Typ.)(CR≥10) |
| goed zicht op | Symmetry |
| kleuren diepte | 16.7M 99% sRGB |
| massa | 600/660g (Typ./Max.) |
| vernieuwingsfrequentie | 60Hz |
| signaal type | LVDS (2 ch, 8-bit) , 30 pins Connector |
| spanningsvoorziening | 3.3V (Typ.) |
| max. waarderingen | Storage Temp.: -20 ~ 70 °C Operating Temp.: -20 ~ 70 °C |
| modelnaam | G156HAN02.1 |
| scherm type | LCM , a-Si TFT-LCD |
| regeling | RGB Vertical Stripe |
| overzicht (mm) | 363.8 × 215.9 × 9.3 (H×V×D) |
| behandeling | Antiglare, Hard coating (3H) |
| contrast ratio | 1000 : 1 (Typ.) (TM) |
| antwoord | 25 (Typ.)(Tr+Td) ms |
| werk modus | AHVA, Normally Black, Transmissive |
| tegenlicht | WLED , 50K hours , With LED Driver |
| gebruikt voor | Industrial Medical Imaging |
| touch screen | Without |
