| Onderdeel nummer | G150XVN01.2 |
| Merk | AUO |
| Maat | 15.0 |
| Sollicitatie | Industrial Medical I |
| Oplossing | 1024×768 |
| Samenstelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 1500:1 |
| Kleuren | 262K/16.2M |
| Tegenlicht | WLED |
| Koppel | |
| merk | AUO |
| diagonale maat | 15.0 inch |
| pixel formaat | 1024(RGB)×768 [XGA] 85PPI |
| actief gebied | 304.128(H)×228.096(V) mm |
| bezel gebied | 307.2(H)×231.1(V) mm |
| luminantie | 400 cd/m² (Typ.) |
| richting bekijken | Symmetry |
| kijk hoek | 88/88/88/88 (Typ.)(CR≥10) |
| ondersteunende kleur | 262K/16.2M 72% NTSC |
| gewicht | TBD |
| frame rate | 60Hz |
| model | G150XVN01.2 |
| type | a-Si TFT-LCD , LCM |
| configuratie | RGB Vertical Stripe |
| omtrek afm. | 326.5(H)×253.5(V) mm |
| behandeling | Antiglare, Hard coating (3H) |
| contrast ratio | 1500:1 (Typ.) (TM) |
| reactietijd | 20/15 (Typ.)(Tr/Td) |
| bedrijfsmodus | MVA, Normally Black, Transmissive |
| lichtbron | WLED , 50K hours , With LED Driver |
| ontworpen voor | Industrial Medical Imaging |
| aanraakpaneel | Without |
