| Onderdeel nummer | G150XTN06.9 |
| Merk | AUO |
| Maat | 15.0 |
| Sollicitatie | Industrial Outdoor H |
| Oplossing | 1024×768 |
| Samenstelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 800:1 |
| Kleuren | 262K/16.2M |
| Tegenlicht | WLED |
| Koppel | LVDS |
| merk | AUO |
| model | G150XTN06.9 |
| diagonale maat | 15.0 inch |
| type | a-Si TFT-LCD, LCM |
| pixel formaat | 1024(RGB)×768 [XGA] 85PPI |
| configuratie | RGB Vertical Stripe |
| actief gebied | 304.128(H)×228.096(V) mm |
| omtrek afm. | 326.5(H)×253.5(V) ×10(D) mm |
| bezel gebied | 311.9(H)×236.85(V) mm |
| behandeling | Antiglare |
| luminantie | 1600 cd/m² (Typ.) |
| contrast ratio | 800:1 (Typ.) (TM) |
| richting bekijken | - |
| reactietijd | 5.7/2.3 (Typ.)(Tr/Td) |
| kijk hoek | 80/80/70/80 (Typ.)(CR≥10) |
| bedrijfsmodus | TN, Normally White, Transmissive |
| ondersteunende kleur | 262K/16.2M 60% NTSC |
| lichtbron | WLED , 50K hours , With LED Driver |
| gewicht | 1.00Kgs (Max.) |
| ontworpen voor | Industrial Outdoor High Brightness |
| frame rate | 60Hz |
| aanraakpaneel | Without |
| interface-type | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| stroomvoorziening | 3.3V (Typ.) |
| omgeving | Operating Temperature: -30 ~ 70 °C ; Storage Temperature: -30 ~ 70 °C |
| G150XG01 V0 | AUO | 15.0 | 1024×768 |
| G150XG01 V1 | AUO | 15.0 | 1024×768 |
| G150XG01 V2 | AUO | 15.0 | 1024×768 |
| G150XG03 V2 | AUO | 15.0 | 1024×768 |
| G150XG03 V3 | AUO | 15.0 | 1024×768 |
| G150XG03 V5 | AUO | 15.0 | 1024×768 |
| G150XGE-L04 Rev.C4 | Innolux | 15.0 | 1024×768 |
| G150XTN02.0 | AUO | 15.0 | 1024×768 |
| G150XTN06.2 | AUO | 15.0 | 1024×768 |
| G150XTN06.4 | AUO | 15.0 | 1024×768 |
