| Onderdeel nummer | G150XTN03.7 |
| Merk | AUO |
| Maat | 15.0 |
| Sollicitatie | Industrial |
| Oplossing | 1024×768 |
| Samenstelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 500:1 |
| Kleuren | 262K/16.2M |
| Tegenlicht | WLED |
| Koppel | |
| paneel merk | AUO |
| paneel grootte | 15.0" |
| oplossing | 1024(RGB)×768, XGA, 85PPI |
| weergavegebied | 304.128(W)×228.096(H) mm |
| omtrek grootte | 326.5(W)×253.5(H) ×10(D) mm |
| helderheid | 250 cd/m² (Typ.) |
| kijk hoek | 45/45/20/40 (Typ.)(CR≥10) |
| beste zicht op | - |
| kleuren weergeven | 262K/16.2M 60% NTSC |
| frequentie | 60Hz |
| gewicht | 1.02Kgs (Max.) |
| paneelmodel | G150XTN03.7 |
| paneel type | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| omlijsting openen | 313.55(W)×237.25(H) mm |
| oppervlak | Antiglare, Hard coating (3H) |
| contrast ratio | 500:1 (Typ.) (TM) |
| weergavemodus | TN, Normally White, Transmissive |
| reactietijd | 6/2 (Typ.)(Tr/Td) |
| soort lamp | WLED , 50K hours , With LED Driver |
| touch screen | Without |
| sollicitatie | Industrial |
| G150X1-L01 | Innolux | 15.0 | 1024×768 |
| G150XGE-L04 | Innolux | 15.0 | 1024×768 |
| G150XGE-L04 Rev.C4 | Innolux | 15.0 | 1024×768 |
| G150XTN01.0 | AUO | 15.0 | 1024×768 |
| G150XTN01.1 | AUO | 15.0 | 1024×768 |
| G150XTN04.0 | AUO | 15.0 | 1024×768 |
| G150XTN05.0 | AUO | 15.0 | 1024×768 |
| G150XTN06.0 | AUO | 15.0 | 1024×768 |
| G150XTN06.1 | AUO | 15.0 | 1024×768 |
| G150XVN01.0 | AUO | 15.0 | 1024×768 |
