| Onderdeel nummer | G150XTN03.6 |
| Merk | AUO |
| Maat | 15.0 |
| Sollicitatie | Industrial |
| Oplossing | 1024×768 |
| Samenstelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 500:1 |
| Kleuren | 262K/16.2M |
| Tegenlicht | WLED |
| Koppel | LVDS |
| fabrikant | AUO |
| scherm grootte | 15.0 inch |
| pixel nummer | 1024(RGB)×768 (XGA) 85PPI |
| actief gebied (mm) | 304.128 × 228.096 (H×V) |
| bezel gebied (mm) | 313.55 × 237.25 (H×V) |
| luminantie | 250 cd/m² (Typ.) |
| kijk hoek | 45/45/20/40 (Typ.)(CR≥10) |
| goed zicht op | - |
| kleuren diepte | 262K/16.2M 60% NTSC |
| massa | 1.10Kgs (Max.) |
| vernieuwingsfrequentie | 60Hz |
| signaal type | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| spanningsvoorziening | 3.3V (Typ.) |
| max. waarderingen | Storage Temp.: -20 ~ 65 °C Operating Temp.: 0 ~ 65 °C |
| modelnaam | G150XTN03.6 |
| scherm type | LCM , a-Si TFT-LCD |
| regeling | RGB Vertical Stripe |
| overzicht (mm) | 326.5 × 253.5 × 10 (H×V×D) |
| behandeling | Antiglare, Hard coating (3H) |
| contrast ratio | 500 : 1 (Typ.) (TM) |
| antwoord | 5.7/2.3 (Typ.)(Tr/Td) ms |
| werk modus | TN, Normally White, Transmissive |
| tegenlicht | WLED , 50K hours , With LED Driver |
| gebruikt voor | Industrial |
| touch screen | Without |
