| Onderdeel nummer | G150XAN01.0 |
| Merk | AUO |
| Maat | 15.0 |
| Sollicitatie | Industrial |
| Oplossing | 1024×768 |
| Samenstelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleuren | 16.2M |
| Tegenlicht | WLED |
| Koppel | LVDS |
| paneel merk | AUO |
| paneelmodel | G150XAN01.0 |
| paneel grootte | 15.0" |
| paneel type | a-Si TFT-LCD, LCM |
| oplossing | 1024(RGB)×768, XGA, 85PPI |
| pixel formaat | RGB Vertical Stripe |
| weergavegebied | 304.128(W)×228.096(H) mm |
| omlijsting openen | 309.9(W)×236.3(H) mm |
| omtrek grootte | 326.5(W)×253.5(H) ×9(D) mm |
| oppervlak | Antiglare, Hard coating (3H) |
| helderheid | 350 cd/m² (Typ.) |
| contrast ratio | 1000:1 (Typ.) (TM) |
| kijk hoek | 89/89/89/89 (Typ.)(CR≥10) |
| weergavemodus | AHVA, Normally Black, Transmissive |
| beste zicht op | Symmetry |
| reactietijd | 25 (Typ.)(Tr+Td) |
| kleuren weergeven | 16.2M 60% NTSC |
| soort lamp | WLED , 50K hours , With LED Driver |
| frequentie | 60Hz |
| touch screen | Without |
| paneel gewicht | 920g (Max.) |
| sollicitatie | Industrial |
| signaal interface | LVDS (1 ch, 8-bit) , 20 pins Connector |
| ingangsspanning | 3.3V (Typ.) |
| omgeving | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -20 ~ 70 °C |
