| Onderdeel nummer | G121EAN01.4 |
| Merk | AUO |
| Maat | 12.1 |
| Sollicitatie | Industrial Medical I |
| Oplossing | 1280×800 |
| Samenstelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 1000:1 |
| Kleuren | 262K/16.2M |
| Tegenlicht | WLED |
| Koppel | LVDS |
| fabrikant | AUO |
| scherm grootte | 12.1 inch |
| pixel nummer | 1280(RGB)×800 (WXGA) 124PPI |
| actief gebied (mm) | 261.12 × 163.2 (H×V) |
| bezel gebied (mm) | 264.22 × 168.12 (H×V) |
| luminantie | 300 cd/m² (Typ.) |
| kijk hoek | 89/89/89/89 (Typ.)(CR≥10) |
| goed zicht op | Symmetry |
| kleuren diepte | 262K/16.2M 99% sRGB |
| massa | 480g (Max.) |
| vernieuwingsfrequentie | 60Hz |
| signaal type | LVDS (1 ch, 6/8-bit) , 30 pins Connector |
| spanningsvoorziening | 3.3V (Typ.) |
| max. waarderingen | Storage Temp.: -30 ~ 85 °C Operating Temp.: -30 ~ 85 °C |
| modelnaam | G121EAN01.4 |
| scherm type | LCM , a-Si TFT-LCD |
| regeling | RGB Vertical Stripe |
| overzicht (mm) | 278 × 184 × 9.64 (H×V×D) |
| behandeling | Antiglare, Hard coating (3H) |
| contrast ratio | 1000 : 1 (Typ.) (TM) |
| antwoord | 25 (Typ.)(Tr+Td) ms |
| werk modus | AHVA, Normally Black, Transmissive |
| tegenlicht | WLED , 30K hours , With LED Driver |
| gebruikt voor | Industrial Medical Imaging |
| touch screen | Without |
