| Onderdeel nummer | G101STN01.G |
| Merk | AUO |
| Maat | 10.1 |
| Sollicitatie | Industrial |
| Oplossing | 1024×600 |
| Samenstelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 500:1 |
| Kleuren | 262K/16.7M |
| Tegenlicht | WLED |
| Koppel | |
| paneel merk | AUO |
| paneel grootte | 10.1" |
| oplossing | 1024(RGB)×600, WSVGA, 117PPI |
| weergavegebied | 222.72(W)×125.28(H) mm |
| omtrek grootte | 235(W)×143(H) ×5.2(D) mm |
| helderheid | 250 cd/m² (Typ.) |
| kijk hoek | 70/70/60/60 (Typ.)(CR≥10) |
| beste zicht op | - |
| kleuren weergeven | 262K/16.7M 45% NTSC |
| frequentie | 60Hz |
| gewicht | 180g (Typ.) |
| paneelmodel | G101STN01.G (AUO10D2) |
| paneel type | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| omlijsting openen | 226.34(W)×128.1(H) mm |
| oppervlak | Antiglare, Hard coating (3H) |
| contrast ratio | 500:1 (Typ.) (TM) |
| weergavemodus | TN, Normally White, Transmissive |
| reactietijd | 7/9 (Typ.)(Tr/Td) |
| soort lamp | WLED , 15K hours , With LED Driver |
| touch screen | Without |
| sollicitatie | Industrial |
| G101STN01.0 | AUO | 10.1 | 1024×600 |
| G101STN01.2 | AUO | 10.1 | 1024×600 |
| G101STN01.3 | AUO | 10.1 | 1024×600 |
| HSD100IFW1-A02 | HannStar | 10.1 | 1024×600 |
| LP101WH4-SLA6 | LG Display | 10.1 | 1366×768 |
| LP101WS1-TLB1 | LG Display | 10.1 | 1024×576 |
| LTN101NT02-W05 | Samsung | 10.1 | 1024×600 |
| N101ICG-L21 Rev.C2 | Innolux | 10.1 | 1280×800 |
| TV101WXM-NP0 | BOE | 10.1 | 1280×800 |
| VVX10T022N00 | Panasonic | 10.1 | 2560×1600 |
