| Onderdeel nummer | G101STN01.5 |
| Merk | AUO |
| Maat | 10.1 |
| Sollicitatie | Industrial |
| Oplossing | 1024×600 |
| Samenstelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 500:1 |
| Kleuren | 262K/16.7M |
| Tegenlicht | WLED |
| Koppel | Parallel |
| merk | AUO |
| diagonale maat | 10.1 inch |
| pixel formaat | 1024(RGB)×600 [WSVGA] 117PPI |
| actief gebied | 222.72(H)×125.28(V) mm |
| bezel gebied | 226.43(H)×128.1(V) mm |
| luminantie | 350 cd/m² (Typ.) |
| richting bekijken | - |
| kijk hoek | 70/70/60/60 (Typ.)(CR≥10) |
| ondersteunende kleur | 262K/16.7M 45% NTSC |
| gewicht | 340g (Max.) |
| frame rate | 60Hz |
| interface-type | Parallel RGB (1 ch, 6/8-bit) , 50 pins FPC |
| stroomvoorziening | 3.3/10/18/-8V (Typ.)(VDD/AVDD/VGH/VGL) |
| omgeving | Operating Temperature: -10 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C |
| model | G101STN01.5 |
| type | a-Si TFT-LCD , LCM |
| configuratie | RGB Vertical Stripe |
| omtrek afm. | 235(H)×143(V) ×5.5(D) mm |
| behandeling | Antiglare, Hard coating (3H) |
| contrast ratio | 500:1 (Typ.) (TM) |
| reactietijd | 7/9 (Typ.)(Tr/Td) |
| bedrijfsmodus | TN, Normally White, Transmissive |
| lichtbron | WLED , 15K hours , W/O Driver |
| ontworpen voor | Industrial |
| aanraakpaneel | Without |
