| Onderdeel nummer | G101EVT03.2 |
| Merk | AUO |
| Maat | 10.1 |
| Sollicitatie | Industrial |
| Oplossing | 1280×800 |
| Samenstelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 1300:1 |
| Kleuren | 262K |
| Tegenlicht | WLED |
| Koppel | |
| fabrikant | AUO |
| modelnaam | G101EVT03.2 |
| scherm grootte | 10.1 inch |
| scherm type | LCM , a-Si TFT-LCD |
| pixel nummer | 1280(RGB)×800 (WXGA) 149PPI |
| regeling | RGB Vertical Stripe |
| actief gebied (mm) | 216.96 × 135.6 (H×V) |
| overzicht (mm) | - |
| luminantie | - |
| contrast ratio | 1300 : 1 (Typ.) (TM) |
| kijk hoek | 85/85/85/85 (Typ.)(CR≥10) |
| antwoord | 25 (Typ.)(Tr+Td) ms |
| goed zicht op | Symmetry |
| werk modus | MVA, Normally Black, Transmissive |
| kleuren diepte | 262K 45% NTSC |
| tegenlicht | WLED |
| massa | - |
| gebruikt voor | Industrial |
| vernieuwingsfrequentie | 60Hz |
| touch screen | - |
