| Onderdeel nummer | G101EAN02.1 |
| Merk | AUO |
| Maat | 10.1 |
| Sollicitatie | Industrial |
| Oplossing | 1280×800 |
| Samenstelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 800:1 |
| Kleuren | 16.7M |
| Tegenlicht | WLED |
| Koppel | LVDS |
| merk | AUO |
| diagonale maat | 10.1 inch |
| pixel formaat | 1280(RGB)×800 [WXGA] 149PPI |
| actief gebied | 216.96(H)×135.6(V) mm |
| bezel gebied | - |
| luminantie | 400 cd/m² (Typ.) |
| richting bekijken | Symmetry |
| kijk hoek | 89/89/89/89 (Typ.)(CR≥10) |
| ondersteunende kleur | 16.7M 50% NTSC |
| gewicht | 195g (Max.) |
| frame rate | 60Hz |
| interface-type | LVDS (1 ch, 8-bit) , 40 pins Connector |
| stroomvoorziening | 3.3V (Typ.) |
| omgeving | Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -20 ~ 60 °C |
| model | G101EAN02.1 |
| type | a-Si TFT-LCD , LCM |
| configuratie | RGB Vertical Stripe |
| omtrek afm. | 227.72(H)×147.8(V) ×4.8(D) mm |
| behandeling | Hard coating |
| contrast ratio | 800:1 (Typ.) (TM) |
| reactietijd | 29 (Typ.)(Tr+Td) |
| bedrijfsmodus | AHVA, Normally Black, Transmissive |
| lichtbron | WLED , 30K hours , With LED Driver |
| ontworpen voor | Industrial |
| aanraakpaneel | Without |
