| Onderdeel nummer | G101EAN01.0 |
| Merk | AUO |
| Maat | 10.1 |
| Sollicitatie | Industrial |
| Oplossing | 800×1280 |
| Samenstelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 1000:1 |
| Kleuren | 16.7M |
| Tegenlicht | WLED |
| Koppel | |
| fabrikant | AUO |
| scherm grootte | 10.1 inch |
| pixel nummer | 800(RGB)×1280 (WXGA) 150PPI |
| actief gebied (mm) | 135.36 × 216.576 (H×V) |
| bezel gebied (mm) | - |
| luminantie | 350 (Typ.)(cd/m²) |
| kijk hoek | 85/85/85/85 (Typ.)(CR≥10) |
| goed zicht op | Symmetry |
| kleuren diepte | 16.7M 60% NTSC |
| massa | 161g (Max.) |
| vernieuwingsfrequentie | 60Hz |
| modelnaam | G101EAN01.0 |
| scherm type | LCM , a-Si TFT-LCD |
| regeling | RGB Vertical Stripe |
| overzicht (mm) | 150.3 × 232.43 × 4.8 (H×V×D) |
| behandeling | Antiglare, Antireflection |
| contrast ratio | 1000 : 1 (Typ.) (TM) |
| werk modus | AHVA, Normally Black, Transmissive |
| antwoord | 30 (Typ.)(Tr+Td) ms |
| tegenlicht | WLED , 15K hours , No Driver |
| gebruikt voor | Industrial |
| touch screen | Without |
