| Onderdeel nummer | G070VAN01.1 |
| Merk | AUO |
| Maat | 7.0 |
| Sollicitatie | Industrial |
| Oplossing | 800×480 |
| Samenstelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 1300:1 |
| Kleuren | 262K/16.7M |
| Tegenlicht | 7S2P |
| Koppel | LVDS |
| fabrikant | AUO |
| scherm grootte | 7.0 inch |
| pixel nummer | 800×480(RGB) (WVGA) 133PPI |
| actief gebied (mm) | 152.4 × 91.44 (H×V) |
| bezel gebied (mm) | 154.2 × 93.24 (H×V) |
| luminantie | 200 cd/m² (Typ.) |
| kijk hoek | 85/85/85/85 (Typ.)(CR≥10) |
| goed zicht op | Symmetry |
| kleuren diepte | 262K/16.7M 60% NTSC |
| massa | 160g (Typ.) |
| vernieuwingsfrequentie | 60Hz |
| signaal type | LVDS (1 ch, 6/8-bit) , 30 pins Connector |
| spanningsvoorziening | 3.3V (Typ.) |
| max. waarderingen | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| modelnaam | G070VAN01.1 |
| scherm type | LCM , a-Si TFT-LCD |
| regeling | RGB Horizontal Stripe |
| overzicht (mm) | 166.6 × 107 × 10 (H×V×D) |
| behandeling | Antiglare |
| contrast ratio | 1300 : 1 (Typ.) (TM) |
| antwoord | 11/19 (Max.)(Tr/Td) ms |
| werk modus | AHVA, Normally Black, Transmissive |
| tegenlicht | 7S2P WLED , 30K hours , No Driver |
| gebruikt voor | Industrial |
| touch screen | Without |
| G070VTN01.0 | AUO | 7.0 | 800×480 |
| G070VTT01.0 | AUO | 7.0 | 800×480 |
| G070VVN01.0 | AUO | 7.0 | 800×480 |
| G070VVN01.1 | AUO | 7.0 | 800×480 |
| G070VW01 V0 | AUO | 7.0 | 800×480 |
| G070VW01 V1 | AUO | 7.0 | 800×480 |
| HE070IA-04M | Innolux | 7.0 | 800×1280 |
| N070ICN-GB1 | Innolux | 7.0 | 800×1280 |
| TM070JDHP01-00 | Tianma | 7.0 | 1280×800 |
| TX18D40VM1CAA | KOE | 7.0 | 800×480 |
