| Onderdeel nummer | G057QTN01.4 |
| Merk | AUO |
| Maat | 5.7 |
| Sollicitatie | Industrial |
| Oplossing | 320×240 |
| Samenstelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 700:1 |
| Kleuren | 262K |
| Tegenlicht | WLED |
| Koppel | CMOS |
| paneel merk | AUO |
| paneel grootte | 5.7" |
| oplossing | 320(RGB)×240, QVGA, 70PPI |
| weergavegebied | 115.2(W)×86.4(H) mm |
| helderheid | 500 cd/m² (Typ.) |
| kijk hoek | 80/80/70/70 (Typ.)(CR≥10) |
| beste zicht op | - |
| kleuren weergeven | 262K |
| frequentie | 60Hz |
| paneel gewicht | - |
| signaal interface | CMOS (1 ch, 6-bit) |
| omgeving | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -30 ~ 85 °C |
| paneelmodel | G057QTN01.4 |
| paneel type | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| omlijsting openen | - |
| contrast ratio | 700:1 (Typ.) (TM) |
| weergavemodus | TN, Normally White, Transmissive |
| reactietijd | 15/10 (Typ.)(Tr/Td) |
| soort lamp | WLED , 75K hours |
| touch screen | Without |
| sollicitatie | Industrial |
| AA057VF12 | Mitsubishi | 5.7 | 640×480 |
| CLAA057VC01CW | CPT | 5.7 | 640×480 |
| EL320.240.36 ET CC | Lumineq | 5.7 | 320×240 |
| G057QN01 V0 | AUO | 5.7 | 320×240 |
| G057QN01 V1 | AUO | 5.7 | 320×240 |
| G057QN01 V2 | AUO | 5.7 | 320×240 |
| G057QTN01.1 | AUO | 5.7 | 320×240 |
| KCG057QV1DB-G56 | Kyocera | 5.7 | 320×240 |
| LQ057V3DG02 | SHARP | 5.7 | 640×480 |
| NL6448BC18-06F | NLT | 5.7 | 640×480 |
