| Onderdeel nummer | EV121X0M-N10 |
| Merk | BOE |
| Maat | 12.1 |
| Sollicitatie | Industrial |
| Oplossing | 1024×768 |
| Samenstelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 1200:1 |
| Kleuren | 16.7M |
| Tegenlicht | WLED |
| Koppel | LVDS |
| merk | BOE |
| diagonale maat | 12.1 inch |
| pixel formaat | 1024(RGB)×768 [XGA] 105PPI |
| actief gebied | 245.76(H)×184.32(V) mm |
| bezel gebied | 249(H)×187.5(V) mm |
| luminantie | 500 cd/m² (Typ.) |
| richting bekijken | Symmetry |
| kijk hoek | 88/88/88/88 (Typ.)(CR≥10) |
| ondersteunende kleur | 16.7M 72% NTSC |
| gewicht | 520g (Max.) |
| frame rate | 60Hz |
| interface-type | LVDS (1 ch, 8-bit) , 20 pins Connector |
| stroomvoorziening | 3.3V (Typ.) |
| omgeving | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| model | EV121X0M-N10 |
| type | a-Si TFT-LCD , LCM |
| configuratie | RGB Vertical Stripe |
| omtrek afm. | 260.5(H)×204(V) ×9.2(D) mm |
| behandeling | - |
| contrast ratio | 1200:1 (Typ.) (TM) |
| reactietijd | 25 (Typ.)(Tr+Td) |
| bedrijfsmodus | ADS, Normally Black, Transmissive |
| lichtbron | WLED , 50K hours , With LED Driver |
| ontworpen voor | Industrial |
| aanraakpaneel | Without |
