| Onderdeel nummer | ES050YMM-A00 |
| Merk | BOE |
| Maat | 5.0 |
| Sollicitatie | Round Display Instru |
| Oplossing | 1080×1080 |
| Samenstelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 1300:1 |
| Kleuren | 16.7M |
| Tegenlicht | WLED |
| Koppel | |
| fabrikant | BOE |
| modelnaam | ES050YMM-A00 |
| scherm grootte | 5.0 inch |
| scherm type | LCM, a-Si TFT-LCD |
| pixel nummer | 1080(RGB)×1080 215PPI |
| regeling | RGB Vertical Stripe |
| actief gebied (mm) | 127.008 × 127.008 (H×V) |
| overzicht (mm) | 143 × 140 × 4.45 (H×V×D) |
| luminantie | 400 cd/m² (Typ.) |
| contrast ratio | 1300 : 1 (Typ.) (TM) |
| kijk hoek | 80/80/80/80 (Typ.)(CR≥10) |
| antwoord | 40 (Max.)(Tr+Td) ms |
| goed zicht op | Symmetry |
| werk modus | ADS, Normally Black, Transmissive |
| kleuren diepte | 16.7M 80% NTSC |
| tegenlicht | WLED , No Driver |
| massa | - |
| gebruikt voor | Round Display Instruments & Meters Home Appliance |
| vernieuwingsfrequentie | 60Hz |
| touch screen | PCAP |
| Storage Temp.: -30 ~ 75 °C Operating Temp.: -20 ~ 60 °C |
| A050BTS30R0 | Aptus | 5.0 | 480×480 |
| COM50H5125XLC | ORTUSTECH | 5.0 | 320×240 |
| DLC0500EZG-T-6 | Other | 5.0 | 800×480 |
| LH500WF1-SD02 | LG Display | 5.0 | 1080×1920 |
| LQ050Q5DR01 | SHARP | 5.0 | 320×240 |
| LQ050T5DG02 | SHARP | 5.0 | 400×240 |
| LQ050T5DW02 | SHARP | 5.0 | 400×240 |
| LQ5AW136R | SHARP | 5.0 | 320×234 |
| PW050XS3 | E Ink | 5.0 | 320×220 |
| ZJ050NA-08C | Innolux | 5.0 | 640×480 |
