| Onderdeel nummer | ED047TC2 |
| Merk | E Ink |
| Maat | 4.7 |
| Sollicitatie | Mobile Phone |
| Oplossing | 540×960 |
| Samenstelling | EPD, EPD |
| Helderheid | |
| CR | |
| Kleuren | Grayscale |
| Tegenlicht | No |
| Koppel | Parallel |
| merk | E Ink |
| model | ED047TC2 |
| diagonale maat | 4.7 inch |
| type | EPD, EPD |
| pixel formaat | 540×960 [qHD] 235PPI |
| configuratie | Rectangle |
| actief gebied | 58.32(H)×103.68(V) mm |
| omtrek afm. | 62.5(H)×113.9(V) mm |
| bezel gebied | - |
| behandeling | Hard coating |
| richting bekijken | - |
| reactietijd | 450 |
| kijk hoek | - |
| bedrijfsmodus | Reflective |
| ondersteunende kleur | Grayscale |
| lichtbron | No B/L |
| gewicht | 12.0g |
| ontworpen voor | Mobile Phone |
| frame rate | - |
| aanraakpaneel | Without |
| interface-type | Parallel Data (1ch, 8-bit) Connector |
| omgeving | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -25 ~ 70 °C |
