| Onderdeel nummer | E295FCA62.A |
| Merk | EDO |
| Maat | 3.0 |
| Sollicitatie | HMD VR AR |
| Oplossing | 1080×1200 |
| Samenstelling | AM-OLED, OLED |
| Helderheid | |
| CR | 10000:1 |
| Kleuren | 16.7M |
| Tegenlicht | self |
| Koppel | MIPI |
| merk | EDO |
| model | E295FCA62.A |
| diagonale maat | 3.0 inch |
| type | AM-OLED, OLED |
| pixel formaat | 1080(RGB)×1200 446PPI |
| configuratie | Sub-Pixel Rendering |
| actief gebied | 50.11(H)×55.68(V) mm |
| omtrek afm. | 52.91(H)×62.58(V) ×0.75(D) mm |
| luminantie | 300 cd/m² (Typ.) |
| contrast ratio | 10000:1 (Min.) (TM) |
| richting bekijken | Symmetry |
| reactietijd | 2 (Typ.)(Tr+Tf) |
| kijk hoek | 80/80/80/80 (Typ.)(CR≥200) |
| bedrijfsmodus | - |
| ondersteunende kleur | 16.7M 109% NTSC |
| lichtbron | self |
| gewicht | 4.80±0.40g |
| ontworpen voor | HMD VR AR |
| frame rate | 60Hz |
| aanraakpaneel | Without |
| d-ic detail | COG Built-in RM67295 |
| interface-type | MIPI (4 data lanes) , 39 pins FPC |
| stroomvoorziening | 1.8/3.3/6.4/4.6/-2.5V (Typ.)(VDDI/VCI/VSP/ELVDD/ELVSS) |
| omgeving | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -55 ~ 125 °C |
| A030DN05 V0 | AUO | 3.0 | 320×240 |
| A030DW01 V1 | AUO | 3.0 | 320×240 |
| AL2004A | Other | 3.0 | 20×4 |
| C-51505NFJ-SLG-AHN | Kyocera | 3.0 | 20×2 |
| COM30T3N64ZLG | ORTUSTECH | 3.0 | 320×240 |
| DMC-20261NYJ-LY-CDE-CKN | Kyocera | 3.0 | 20×2 |
| DX08D11VM0AAA | KOE | 3.0 | 480×800 |
| EQ030AS181 | PDI | 3.0 | 320×240 |
| LH300WQ1-ED01 | LG Display | 3.0 | 240×400 |
| TD030MHEB3 | TPO | 3.0 | 320×240 |
