| Onderdeel nummer | COM55T5103RSP |
| Merk | CASIO |
| Maat | 5.5 |
| Sollicitatie | Industrial |
| Oplossing | 320×234 |
| Samenstelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 60:1 |
| Kleuren | Full |
| Tegenlicht | 1 |
| Koppel | Analog |
| paneel merk | CASIO |
| paneel grootte | 5.5" |
| oplossing | 320(RGB)×234, 72PPI |
| weergavegebied | 110.4(W)×83.538(H) mm |
| omtrek grootte | 163(W)×115(H) ×32.5(D) mm |
| helderheid | 350 cd/m² (Typ.) |
| kijk hoek | 35/35/30/35 (Typ.)(CR≥10) |
| beste zicht op | 12 o'clock |
| kleuren weergeven | Full color |
| frequentie | 60Hz |
| paneel gewicht | 400g (Typ.) |
| signaal interface | Analog RGB , 12 pins Connector |
| ingangsspanning | 12.0V (Typ.) |
| omgeving | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -10 ~ 60 °C |
| paneelmodel | COM55T5103RSP |
| paneel type | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| omlijsting openen | - |
| oppervlak | - |
| contrast ratio | 60:1 (Min.) (TM) |
| weergavemodus | TN, Normally White, Transmissive |
| reactietijd | - |
| soort lamp | 1 pcs CCFL , With Inverter |
| touch screen | Without |
| sollicitatie | Industrial |
| BT055FWM-N00 | BOE | 5.5 | 480×854 |
| CM546B1-002 | CSOT | 5.5 | 1080×1920 |
| LH550WF2-SD01 | LG Display | 5.5 | 1080×1920 |
| LM32C041 | SHARP | 5.5 | 320×240 |
| LM6Q35 | SHARP | 5.5 | 320×240 |
| LQ055T3SX04 | SHARP | 5.5 | 1080×1920 |
| LS055R1SC01 | SHARP | 5.5 | 1440×2560 |
| NL3224AC35-01 | NLT | 5.5 | 320×240 |
| NL3224BC35-20R | NLT | 5.5 | 320×240 |
| TM055XDHP10 | Tianma | 5.5 | 540×960 |
