| Onderdeel nummer | CM546B2-001 |
| Merk | CSOT |
| Maat | 5.5 |
| Sollicitatie | Mobile Phone |
| Oplossing | 1080×1920 |
| Samenstelling | LTPS TFT-LCD, CELL |
| Helderheid | |
| CR | 1500:1 |
| Kleuren | 16.7M |
| Tegenlicht | No |
| Koppel | |
| paneel merk | CSOT |
| paneelmodel | CM546B2-001 |
| paneel grootte | 5.5" |
| paneel type | LTPS TFT-LCD, CELL |
| oplossing | 1080(RGB)×1920, FHD, 403PPI |
| pixel formaat | RGB Vertical Stripe |
| weergavegebied | 68.04(W)×120.96(H) mm |
| omlijsting openen | - |
| omtrek grootte | 69.44(W)×126.81(H) ×0.45(D) mm |
| oppervlak | With Polarizer |
| helderheid | 0 cd/m² |
| contrast ratio | 1500:1 (Typ.) (TM) |
| kijk hoek | 80/80/80/80 (Typ.)(CR≥10) |
| weergavemodus | FFS, Normally Black, Transmissive |
| beste zicht op | Symmetry |
| reactietijd | 35 (Typ.)(Tr+Td) |
| glas diepte | 0.15+0.15 mm |
| doorlaatbaarheid | 4.69% (Typ.)(with APCF) |
| kleuren weergeven | 16.7M 80% NTSC |
| soort lamp | No B/L |
| frequentie | - |
| touch screen | In-Cell Touch |
| bestuurder ic | COG Built-in TD4310 |
| paneel gewicht | TBD |
| sollicitatie | Mobile Phone |
| omgeving | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
