| Onderdeel nummer | CLAA080WK0A XN |
| Merk | CPT |
| Maat | 8.0 |
| Sollicitatie | Automotive Display |
| Oplossing | 1280×720 |
| Samenstelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 900:1 |
| Kleuren | 16.7M |
| Tegenlicht | WLED |
| Koppel | |
| merk | CPT |
| model | CLAA080WK0A XN |
| diagonale maat | 8.0 inch |
| type | a-Si TFT-LCD, LCM |
| pixel formaat | 1280(RGB)×720 [WXGA] 183PPI |
| configuratie | RGB Vertical Stripe |
| actief gebied | 177.024(H)×99.576(V) mm |
| omtrek afm. | 182.8(H)×116.9(V) ×6.8(D) mm |
| bezel gebied | 179.024(H)×101.576(V) mm |
| behandeling | Antiglare (Haze 25%), Hard coating (3H) |
| luminantie | 600 cd/m² (Typ.) |
| contrast ratio | 900:1 (Typ.) (TM) |
| richting bekijken | Symmetry |
| reactietijd | 25 (Typ.)(Tr+Td) |
| kijk hoek | 85/85/85/85 (Typ.)(CR≥10) |
| bedrijfsmodus | HFFS, Normally Black, Transmissive |
| ondersteunende kleur | 16.7M 70% NTSC |
| lichtbron | WLED [9S3P] , 50K hours , W/O Driver |
| gewicht | 120/230g (Typ./Max.) |
| ontworpen voor | Automotive Display |
| frame rate | 60Hz |
| aanraakpaneel | Without |
| Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C ; Vibration Level: 2.9G (28.4 m/s²) |
