| Onderdeel nummer | CC500PV6D |
| Merk | PANDA |
| Maat | 50 |
| Sollicitatie | TV Sets |
| Oplossing | 3840×2160 |
| Samenstelling | Oxide TFT-LCD, CELL |
| Helderheid | |
| CR | 6000:1 |
| Kleuren | 1.07B |
| Tegenlicht | No |
| Koppel | USI-T |
| paneel merk | PANDA |
| paneelmodel | CC500PV6D |
| paneel grootte | 50" |
| paneel type | Oxide TFT-LCD, CELL |
| oplossing | 3840(RGB)×2160, UHD, 89PPI |
| pixel formaat | RGB Vertical Stripe |
| weergavegebied | 1095.8(W)×616.41(H) mm |
| omlijsting openen | - |
| omtrek grootte | 1105.84(W)×627.91(H) ×1.37(D) mm |
| oppervlak | Antiglare (Haze 2.3%), Hard coating (3H) |
| helderheid | 0 cd/m² |
| contrast ratio | 6000:1 (Typ.) (TM) |
| kijk hoek | 89/89/89/89 (Typ.)(CR≥10) |
| weergavemodus | UV2A, Normally Black, Transmissive |
| beste zicht op | Symmetry |
| reactietijd | 8 (Typ.)(G to G) |
| glas diepte | 0.50+0.50 mm |
| doorlaatbaarheid | 5.0% (Typ.)(with Polarizer) |
| kleuren weergeven | 1.07B 70% NTSC |
| soort lamp | No B/L |
| frequentie | 60Hz |
| touch screen | Without |
| bestuurder ic | COF Built-in 12 source chips |
| paneel gewicht | 2.15Kgs (Typ.) |
| sollicitatie | TV Sets |
| signaal interface | USI-T , 96 pins Connector |
| omgeving | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 65 °C |
