| Onderdeel nummer | CC495PU1L |
| Merk | PANDA |
| Maat | 50 |
| Sollicitatie | TV Sets |
| Oplossing | 3840×2160 |
| Samenstelling | CELL , Oxide TFT-L |
| Helderheid | |
| CR | 5000:1 |
| Kleuren | 1.07B |
| Tegenlicht | No |
| Koppel | V-by-One |
| fabrikant | PANDA |
| modelnaam | CC495PU1L |
| scherm grootte | 50 inch |
| scherm type | CELL , Oxide TFT-LCD |
| pixel nummer | 3840(RGB)×2160 (UHD) 89PPI |
| regeling | RGB Vertical Stripe |
| actief gebied (mm) | 1095.84 × 616.41 (H×V) |
| overzicht (mm) | 1106.8 × 628.01 × 1.37 (H×V×D) |
| bezel gebied (mm) | - |
| behandeling | Antiglare, Hard coating (2H) |
| luminantie | 0 cd/m² |
| contrast ratio | 5000 : 1 (Typ.) (TM) |
| kijk hoek | 89/89/89/89 (Typ.)(CR≥10) |
| antwoord | 8 (Typ.)(G to G) ms |
| goed zicht op | Symmetry |
| werk modus | ASV, Normally Black, Transmissive |
| glas dikte | 0.50+0.50 mm |
| doorlaatbaarheid | 5.5% (Typ.)(with Polarizer) |
| kleuren diepte | 1.07B 72% NTSC |
| tegenlicht | No B/L |
| massa | 2.06Kgs (Typ.) |
| gebruikt voor | TV Sets |
| vernieuwingsfrequentie | 60Hz |
| touch screen | Without |
| driver ic lijst | Built-in COF 12 source + 12 gate chips |
| signaal type | V-by-One 8 lane , 51 pins Connector |
| spanningsvoorziening | 12.0V (Typ.) |
| max. waarderingen | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
