| Onderdeel nummer | C090EAN04.1 |
| Merk | AUO |
| Maat | 9.0 |
| Sollicitatie | Outdoor High Brightn |
| Oplossing | 1280×720 |
| Samenstelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleuren | 16.7M |
| Tegenlicht | WLED |
| Koppel | LVDS |
| merk | AUO |
| model | C090EAN04.1 |
| diagonale maat | 9.0 inch |
| type | a-Si TFT-LCD, LCM |
| pixel formaat | 1280(RGB)×720 [WXGA] 163PPI |
| configuratie | RGB Vertical Stripe |
| actief gebied | 198.72(H)×111.78(V) mm |
| omtrek afm. | 212.2(H)×127.9(V) ×11(D) mm |
| bezel gebied | 202.02(H)×115.78(V) mm |
| behandeling | Antiglare |
| luminantie | 900 cd/m² (Typ.) |
| contrast ratio | 1000:1 (Typ.) (TM) |
| richting bekijken | Symmetry |
| reactietijd | 30 (Typ.)(Tr+Td) |
| kijk hoek | 80/80/80/80 (Typ.)(CR≥10) |
| bedrijfsmodus | AHVA, Normally Black, Transmissive |
| ondersteunende kleur | 16.7M 72% NTSC |
| lichtbron | WLED [8S3P] , 10K hours , W/O Driver |
| gewicht | TBD |
| ontworpen voor | Outdoor High Brightness Automotive Display |
| frame rate | 60Hz |
| aanraakpaneel | Without |
| interface-type | LVDS (1 ch, 8-bit) , 40 pins FPC |
| stroomvoorziening | 3.3V (Typ.) |
| omgeving | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C ; Vibration Level: 2.9G (28.4 m/s²) |
