| Onderdeel nummer | C084XAN01.0 |
| Merk | AUO |
| Maat | 8.4 |
| Sollicitatie | Automotive Display |
| Oplossing | 1024×768 |
| Samenstelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 800:1 |
| Kleuren | 16.7M |
| Tegenlicht | WLED |
| Koppel | LVDS |
| fabrikant | AUO |
| scherm grootte | 8.4 inch |
| pixel nummer | 1024(RGB)×768 (XGA) 152PPI |
| actief gebied (mm) | 170.496 × 127.872 (H×V) |
| luminantie | - |
| kijk hoek | - |
| goed zicht op | Symmetry |
| kleuren diepte | 16.7M |
| massa | - |
| vernieuwingsfrequentie | 60Hz |
| signaal type | LVDS (1 ch, 8-bit) , 40 pins Connector |
| max. waarderingen | Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C |
| modelnaam | C084XAN01.0 |
| scherm type | LCM , a-Si TFT-LCD |
| regeling | RGB Vertical Stripe |
| overzicht (mm) | - |
| contrast ratio | 800 : 1 (Typ.) (TM) |
| antwoord | 30 (Max.)(Tr+Td) ms |
| werk modus | AHVA, Normally Black, Transmissive |
| tegenlicht | WLED |
| gebruikt voor | Automotive Display |
| touch screen | Without |
