| Onderdeel nummer | BV050HDE-NBA-3Q00 |
| Merk | BOE |
| Maat | 5.0 |
| Sollicitatie | Mobile Phone |
| Oplossing | 720×1280 |
| Samenstelling | a-Si TFT-LCD, CELL |
| Helderheid | |
| CR | 1000:1 |
| Kleuren | 16.7M |
| Tegenlicht | No |
| Koppel | |
| paneel merk | BOE |
| paneelmodel | BV050HDE-NBA-3Q00 |
| paneel grootte | 5.0" |
| paneel type | a-Si TFT-LCD, CELL |
| oplossing | 720(RGB)×1280, WXGA, 294PPI |
| pixel formaat | RGB Vertical Stripe |
| weergavegebied | 62.1(W)×110.4(H) mm |
| omlijsting openen | - |
| helderheid | 0 cd/m² |
| contrast ratio | 1000:1 (Typ.) (TM) |
| kijk hoek | 80/80/80/80 (Typ.)(CR≥10) |
| weergavemodus | ADS, Normally Black, Transmissive |
| beste zicht op | Symmetry |
| reactietijd | 25 (Typ.)(Tr+Td) |
| kleuren weergeven | 16.7M 70% NTSC |
| soort lamp | No B/L |
| frequentie | - |
| touch screen | Without |
| paneel gewicht | - |
| sollicitatie | Mobile Phone |
| omgeving | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| A050FW03 V0 | AUO | 5.0 | 480×272 |
| AM-800480LTMQW-W0H | AMPIRE | 5.0 | 800×480 |
| CLAN050LH21 1XB | CPT | 5.0 | 540×960 |
| CLAN050LL31 1XG | CPT | 5.0 | 480×800 |
| H497TLB01.4 | AUO | 5.0 | 720×1280 |
| HJ050NA-01I | Innolux | 5.0 | 800×480 |
| LMS500HF05 | Samsung | 5.0 | 480×272 |
| LQ5AW136 | SHARP | 5.0 | 320×234 |
| P50AD2 | E Ink | 5.0 | 320×234 |
| PA050XS1 | E Ink | 5.0 | 320×234 |
