| Onderdeel nummer | BB050HDG-TC1-6D00 |
| Merk | BOE |
| Maat | 5.0 |
| Sollicitatie | Mobile Phone |
| Oplossing | 720×1280 |
| Samenstelling | AM-OLED, OLED |
| Helderheid | |
| CR | 17000:1 |
| Kleuren | 16.7M |
| Tegenlicht | self |
| Koppel | MIPI |
| paneel merk | BOE |
| paneelmodel | BB050HDG-TC1-6D00 |
| paneel grootte | 5.0" |
| paneel type | AM-OLED, OLED |
| oplossing | 720(RGB)×1280, WXGA, 295PPI |
| pixel formaat | RGB Vertical Stripe |
| weergavegebied | 61.92(W)×110.08(H) mm |
| omlijsting openen | - |
| omtrek grootte | 64.12(W)×116.72(H) mm |
| oppervlak | Hard coating |
| helderheid | 350 cd/m² (Typ.) |
| contrast ratio | 17000:1 (Typ.) (TM) |
| kijk hoek | 80/80/80/80 (Min.) |
| weergavemodus | OLED |
| beste zicht op | Symmetry |
| reactietijd | - |
| kleuren weergeven | 16.7M 101% NTSC |
| soort lamp | self , 10K hours |
| frequentie | 60Hz |
| touch screen | On-Cell Touch |
| bestuurder ic | COG Built-in RM67120 |
| paneel gewicht | TBD |
| sollicitatie | Mobile Phone |
| signaal interface | MIPI (4 data lanes) |
| ingangsspanning | 2.8/1.8/6.0/4.6/-3.4V (Typ.)(VCI/VDDIO/AVDD/ELVDD/ELVSS) |
| omgeving | Operating Temp.: -20 ~ 60 °C ; Storage Temp.: -30 ~ 70 °C |
| BB050HDG-T40 | BOE | 5.0 | 720×1280 |
| BTL507212-W746L | BOE | 5.0 | 720×1280 |
| H497TLB01 | AUO | 5.0 | 720×1280 |
| HSD050FMW2-D00 | HannStar | 5.0 | 540×960 |
| LMS500HF07 | Samsung | 5.0 | 480×272 |
| LQ050T3GG01 | SHARP | 5.0 | 400×234 |
| M050SWN1 R2 | IVO | 5.0 | 480×234 |
| P50AN3 | E Ink | 5.0 | 320×234 |
| PA050XU4 | E Ink | 5.0 | 320×234 |
| YXDK050TN02-40NM03 | SEBO | 5.0 | 800×480 |
