| Onderdeel nummer | B173ZAN03.5 |
| Merk | AUO |
| Maat | 17.3 |
| Sollicitatie | Laptop Gaming |
| Oplossing | 3840×2160 |
| Samenstelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleuren | 1.07B |
| Tegenlicht | WLED |
| Koppel | eDP |
| merk | AUO |
| diagonale maat | 17.3 inch |
| pixel formaat | 3840(RGB)×2160 [UHD] 255PPI |
| actief gebied | 381.89(H)×214.81(V) mm |
| luminantie | 500 cd/m² (Typ.) |
| richting bekijken | Symmetry |
| kijk hoek | 85/85/85/85 (Typ.)(CR≥10) |
| ondersteunende kleur | 1.07B 100% NTSC |
| vorm stijl | Slim (PCBA Flat, T≤3.2mm) |
| frame rate | 120Hz |
| interface-type | eDP (4 Lanes) , eDP1.4a , 40 pins Connector |
| stroomvoorziening | 3.3V (Typ.) |
| omgeving | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| model | B173ZAN03.5 (AUO2892) |
| type | a-Si TFT-LCD , LCM |
| configuratie | RGB Vertical Stripe |
| omtrek afm. | 389.89(H)×238.31(V) ×3.5(D) mm |
| contrast ratio | 1000:1 (Min.) (TM) |
| reactietijd | 10 (Typ.)(Tr+Td); 8.3 (Typ.)(G to G) |
| bedrijfsmodus | AHVA, Normally Black, Transmissive |
| lichtbron | WLED , 15K hours , With LED Driver |
| ontworpen voor | Laptop Gaming |
| aanraakpaneel | Without |
