| Onderdeel nummer | B173ZAN03.3 |
| Merk | AUO |
| Maat | 17.3 |
| Sollicitatie | Laptop |
| Oplossing | 3840×2160 |
| Samenstelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleuren | 16.7M |
| Tegenlicht | WLED |
| Koppel | eDP |
| paneel merk | AUO |
| paneelmodel | B173ZAN03.3 (AUOA988) |
| paneel grootte | 17.3" |
| paneel type | a-Si TFT-LCD, LCM |
| oplossing | 3840(RGB)×2160, UHD, 255PPI |
| pixel formaat | RGB Vertical Stripe |
| weergavegebied | 381.89(W)×214.81(H) mm |
| omlijsting openen | - |
| omtrek grootte | 389.89(W)×238.31(H) ×3.5(D) mm |
| oppervlak | Antiglare |
| helderheid | 400 cd/m² (Typ.) |
| contrast ratio | 1000:1 (Typ.) (TM) |
| kijk hoek | 85/85/85/85 (Typ.)(CR≥10) |
| weergavemodus | AHVA, Normally Black, Transmissive |
| beste zicht op | Symmetry |
| reactietijd | 10 (Typ.)(Tr+Td); 8.3 (Typ.)(G to G) |
| kleuren weergeven | 16.7M 100% Adobe RGB |
| soort lamp | WLED , 15K hours , With LED Driver |
| frequentie | 120Hz |
| touch screen | Without |
| vorm stijl | Slim (PCBA Flat, T≤3.2mm) |
| sollicitatie | Laptop |
| signaal interface | eDP (4 Lanes) , eDP1.3 , 40 pins Connector |
| ingangsspanning | 3.3V (Typ.) |
| omgeving | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
