| Onderdeel nummer | B173HAN01.4 |
| Merk | AUO |
| Maat | 17.3 |
| Sollicitatie | Laptop Gaming |
| Oplossing | 1920×1080 |
| Samenstelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 700:1 |
| Kleuren | 16.2M |
| Tegenlicht | WLED |
| Koppel | eDP |
| paneel merk | AUO |
| paneelmodel | B173HAN01.4 (AUO149D) |
| paneel grootte | 17.3" |
| paneel type | a-Si TFT-LCD, LCM |
| oplossing | 1920(RGB)×1080, FHD, 127PPI |
| pixel formaat | RGB Vertical Stripe |
| weergavegebied | 381.888(W)×214.812(H) mm |
| omlijsting openen | - |
| omtrek grootte | 398.1(W)×250.5(H) ×4(D) mm |
| oppervlak | Antiglare, Hard coating (3H) |
| helderheid | 300 cd/m² (Typ.) |
| contrast ratio | 700:1 (Typ.) (TM) |
| kijk hoek | 85/85/85/85 (Typ.)(CR≥10) |
| weergavemodus | AHVA, Normally Black, Transmissive |
| beste zicht op | Symmetry |
| reactietijd | 25 (Typ.)(Tr+Td) |
| kleuren weergeven | 16.2M 72% NTSC |
| soort lamp | WLED , 15K hours , With LED Driver |
| frequentie | 120Hz |
| touch screen | Without |
| vorm stijl | Flat (PCBA Flat, T3.4~4.0mm) |
| sollicitatie | Laptop Gaming |
| signaal interface | eDP (4 Lanes) , eDP1.4a , 40 pins Connector |
| ingangsspanning | 3.3V (Typ.) |
| omgeving | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| B173HAN01.0 | AUO | 17.3 | 1920×1080 |
| B173HTN01.1 | AUO | 17.3 | 1920×1080 |
| B173HW01 V4 | AUO | 17.3 | 1920×1080 |
| B173HW01 V5 | AUO | 17.3 | 1920×1080 |
| B173HW02 V1 | AUO | 17.3 | 1920×1080 |
| B173RW01 V3 | AUO | 17.3 | 1600×900 |
| HSD173PUW1-A00 | HannStar | 17.3 | 1920×1080 |
| LP173WF2-TPB1 | LG Display | 17.3 | 1920×1080 |
| LP173WF3-SLB2 | LG Display | 17.3 | 1920×1080 |
| N173FGE-L23 | Innolux | 17.3 | 1600×900 |
