| Onderdeel nummer | B156XTN07.0 HW1A |
| Merk | AUO |
| Maat | 15.6 |
| Sollicitatie | Laptop |
| Oplossing | 1366×768 |
| Samenstelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 500:1 |
| Kleuren | 262K |
| Tegenlicht | WLED |
| Koppel | |
| merk | AUO |
| diagonale maat | 15.6 inch |
| pixel formaat | 1366(RGB)×768 [WXGA] 100PPI |
| actief gebied | 344.232(H)×193.536(V) mm |
| bezel gebied | - |
| luminantie | 200 cd/m² (Typ.) |
| richting bekijken | 6 o'clock |
| kijk hoek | 45/45/15/35 (Typ.)(CR≥10) |
| ondersteunende kleur | 262K 45% NTSC |
| vorm stijl | Slim (PCBA Flat, T≤3.2mm) |
| frame rate | 60Hz |
| model | B156XTN07.0 HW1A (AUO10EC) |
| type | a-Si TFT-LCD , LCM |
| configuratie | RGB Vertical Stripe |
| omtrek afm. | 359.5(H)×223.8(V) ×3.2(D) mm |
| behandeling | Glare (Haze 0%) |
| contrast ratio | 500:1 (Typ.) (TM) |
| reactietijd | 8 (Typ.)(Tr+Td) |
| bedrijfsmodus | TN, Normally White, Transmissive |
| lichtbron | WLED , 15K hours , With LED Driver |
| ontworpen voor | Laptop |
| aanraakpaneel | Without |
