| Onderdeel nummer | B140XTN07.6 |
| Merk | AUO |
| Maat | 14.0 |
| Sollicitatie | Laptop |
| Oplossing | 1366×768 |
| Samenstelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 500:1 |
| Kleuren | 262K |
| Tegenlicht | WLED |
| Koppel | |
| fabrikant | AUO |
| modelnaam | B140XTN07.6 |
| scherm grootte | 14.0 inch |
| scherm type | LCM, a-Si TFT-LCD |
| pixel nummer | 1366(RGB)×768 (WXGA) 112PPI |
| regeling | RGB Vertical Stripe |
| actief gebied (mm) | 309.399 × 173.952 (H×V) |
| overzicht (mm) | - |
| luminantie | 220 cd/m² (Typ.) |
| contrast ratio | 500 : 1 (Typ.) (TM) |
| kijk hoek | 45/45/15/40 (Typ.)(CR≥10) |
| antwoord | - |
| goed zicht op | - |
| werk modus | TN, Normally White, Transmissive |
| kleuren diepte | 262K |
| tegenlicht | WLED , With LED Driver |
| omlijnde vorm | Slim (PCBA Flat, T≤3.2mm) |
| gebruikt voor | Laptop |
| vernieuwingsfrequentie | 60Hz |
| touch screen | Without |
| Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
