| Onderdeel nummer | B140QAN02.2 |
| Merk | AUO |
| Maat | 14.0 |
| Sollicitatie | Laptop |
| Oplossing | 2560×1440 |
| Samenstelling | LTPS TFT-LCD, LCM |
| Helderheid | |
| CR | 1500:1 |
| Kleuren | 16.7M |
| Tegenlicht | WLED |
| Koppel | eDP |
| paneel merk | AUO |
| paneelmodel | B140QAN02.2 |
| paneel grootte | 14.0" |
| paneel type | LTPS TFT-LCD, LCM |
| oplossing | 2560(RGB)×1440, Quad-HD, 210PPI |
| pixel formaat | RGB Vertical Stripe |
| weergavegebied | 309.35(W)×174.01(H) mm |
| omlijsting openen | - |
| omtrek grootte | 315.05(W)×195.6(H) ×2.4(D) mm |
| oppervlak | Hard coating (3H) |
| helderheid | - |
| contrast ratio | 1500:1 (Typ.) (TM) |
| kijk hoek | 85/85/85/85 (Typ.)(CR≥10) |
| weergavemodus | AHVA, Normally Black, Transmissive |
| beste zicht op | Symmetry |
| reactietijd | 25 (Typ.)(Tr+Td) |
| kleuren weergeven | 16.7M |
| soort lamp | WLED , 15K hours , With LED Driver |
| frequentie | 60Hz |
| touch screen | Without |
| vorm stijl | Slim (PCBA Flat, T≤3.2mm) |
| sollicitatie | Laptop |
| signaal interface | eDP (4 Lanes) Connector |
| ingangsspanning | 3.3V (Typ.) |
| omgeving | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| B140QAN01.0 | AUO | 14.0 | 2560×1440 |
| B140QAN01.1 | AUO | 14.0 | 2560×1440 |
| B140XW01 V4 | AUO | 14.0 | 1366×768 |
| BT140GW02 V.2 | Innolux | 14.0 | 1366×768 |
| BT140GW03 V.2 | Innolux | 14.0 | 1366×768 |
| LP140WH2-TLEA | LG Display | 14.0 | 1366×768 |
| LTN140AT07-401 | Samsung | 14.0 | 1366×768 |
| LTN140AT16-401 | Samsung | 14.0 | 1366×768 |
| LTN140AT21-801 | Samsung | 14.0 | 1366×768 |
| N140BGE-L33 | Innolux | 14.0 | 1366×768 |
