| Onderdeel nummer | B133HAN06.0 |
| Merk | AUO |
| Maat | 13.3 |
| Sollicitatie | Laptop |
| Oplossing | 1920×1080 |
| Samenstelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 600:1 |
| Kleuren | 262K |
| Tegenlicht | WLED |
| Koppel | eDP |
| fabrikant | AUO |
| modelnaam | B133HAN06.0 (AUO602D) |
| scherm grootte | 13.3 inch |
| scherm type | LCM , a-Si TFT-LCD |
| pixel nummer | 1920(RGB)×1080 (FHD) 166PPI |
| regeling | RGB Vertical Stripe |
| actief gebied (mm) | 293.76 × 165.24 (H×V) |
| overzicht (mm) | 305.35 × 193.45 × 2.85 (H×V×D) |
| bezel gebied (mm) | - |
| behandeling | Antiglare |
| luminantie | 220 cd/m² (Typ.) |
| contrast ratio | 600 : 1 (Typ.) (TM) |
| kijk hoek | 85/85/85/85 (Typ.)(CR≥10) |
| antwoord | 27 (Typ.)(Tr+Tf) ms |
| goed zicht op | Symmetry |
| werk modus | AHVA, Normally Black, Transmissive |
| kleuren diepte | 262K 45% NTSC |
| tegenlicht | WLED , 15K hours , With LED Driver |
| omlijnde vorm | Slim (PCBA Flat, T≤3.2mm) |
| gebruikt voor | Laptop |
| vernieuwingsfrequentie | 60Hz |
| touch screen | Without |
| signaal type | eDP (2 Lanes) , eDP1.2 , 30 pins Connector |
| spanningsvoorziening | 3.3V (Typ.) |
| max. waarderingen | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| B133HAN02.0 | AUO | 13.3 | 1920×1080 |
| B133HAN02.1 | AUO | 13.3 | 1920×1080 |
| B133HAN02.5 | AUO | 13.3 | 1920×1080 |
| B133HAN03.0 | AUO | 13.3 | 1920×1080 |
| B133HAT02.5 | AUO | 13.3 | 1920×1080 |
| LP133WH2-TLL2 | LG Display | 13.3 | 1366×768 |
| LP133WP1-TJA7 | LG Display | 13.3 | 1440×900 |
| LTD133EQ1B | TOSHIBA | 13.3 | 1280×800 |
| N133BGE-LB1 | Innolux | 13.3 | 1366×768 |
| N133HSE-EA1 | Innolux | 13.3 | 1920×1080 |
