| Onderdeel nummer | B133HAN05.F |
| Merk | AUO |
| Maat | 13.3 |
| Sollicitatie | Laptop |
| Oplossing | 1920×1080 |
| Samenstelling | LTPS TFT-LCD, LCM |
| Helderheid | |
| CR | 1400:1 |
| Kleuren | 16.7M |
| Tegenlicht | WLED |
| Koppel | eDP |
| paneel merk | AUO |
| paneelmodel | B133HAN05.F (AUO5F2D) |
| paneel grootte | 13.3" |
| paneel type | LTPS TFT-LCD, LCM |
| oplossing | 1920(RGB)×1080, FHD, 166PPI |
| pixel formaat | RGB Vertical Stripe |
| weergavegebied | 293.76(W)×165.24(H) mm |
| omlijsting openen | - |
| helderheid | 300 cd/m² (Typ.) |
| contrast ratio | 1400:1 (Typ.) (TM) |
| kijk hoek | 85/85/85/85 (Typ.)(CR≥10) |
| weergavemodus | AHVA, Normally Black, Transmissive |
| beste zicht op | Symmetry |
| reactietijd | 27/35 (Typ./Max.)(Tr+Td) |
| kleuren weergeven | 16.7M |
| soort lamp | WLED , 15K hours , With LED Driver |
| frequentie | 60Hz |
| touch screen | Without |
| vorm stijl | - |
| sollicitatie | Laptop |
| signaal interface | eDP (2 Lanes) , eDP1.3 , 30 pins Connector |
| ingangsspanning | 3.3V (Typ.) |
| omgeving | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| B133EW05 V0 | AUO | 13.3 | 1280×800 |
| B133HAN02.0 | AUO | 13.3 | 1920×1080 |
| B133HAN02.1 | AUO | 13.3 | 1920×1080 |
| B133HAN02.5 | AUO | 13.3 | 1920×1080 |
| B133HAN03.0 | AUO | 13.3 | 1920×1080 |
| B133HAT02.5 | AUO | 13.3 | 1920×1080 |
| LP133WX2-TLA2 | LG Display | 13.3 | 1280×800 |
| LQ133T1JW19 | SHARP | 13.3 | 2560×1440 |
| LTN133AT09-W01 | Samsung | 13.3 | 1280×800 |
| LTN133AT23-X01 | Samsung | 13.3 | 1366×768 |
