| Onderdeel nummer | B116XAB01.3 |
| Merk | AUO |
| Maat | 11.6 |
| Sollicitatie | Laptop |
| Oplossing | 1366×768 |
| Samenstelling | a-Si TFT-LCD, Assemb |
| Helderheid | |
| CR | 800:1 |
| Kleuren | 16.7M |
| Tegenlicht | WLED |
| Koppel | eDP |
| merk | AUO |
| model | B116XAB01.3 (AUO288C) |
| diagonale maat | 11.6 inch |
| type | a-Si TFT-LCD, Assembly |
| pixel formaat | 1366(RGB)×768 [WXGA] 135PPI |
| configuratie | RGB Vertical Stripe |
| actief gebied | 256.125(H)×144(V) mm |
| omtrek afm. | 284.85(H)×189.84(V) ×4.2(D) mm |
| bezel gebied | - |
| behandeling | Glare (Haze 0%), Hard coating (7H) |
| luminantie | 220 cd/m² (Typ.) |
| contrast ratio | 800:1 (Typ.) (TM) |
| richting bekijken | Symmetry |
| reactietijd | 27 (Typ.)(Tr+Td) |
| kijk hoek | 85/85/85/85 (Typ.)(CR≥10) |
| bedrijfsmodus | - |
| ondersteunende kleur | 16.7M 50% NTSC |
| lichtbron | WLED , 15K hours , With LED Driver |
| vorm stijl | - |
| ontworpen voor | Laptop |
| frame rate | 60Hz |
| aanraakpaneel | On-Cell Touch |
| interface-type | eDP (2 Lanes) , eDP1.2 , 40 pins Connector |
| stroomvoorziening | 3.3V (Typ.) |
| omgeving | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| B116XAN03.0 HW3A | AUO | 11.6 | 1366×768 |
| B116XAN03.1 HW0A | AUO | 11.6 | 1366×768 |
| B116XAN03.1 HW1A | AUO | 11.6 | 1366×768 |
| B116XTN01.0 HW1A | AUO | 11.6 | 1366×768 |
| B116XTN01.0 HW5A | AUO | 11.6 | 1366×768 |
| B116XTT01.1 | AUO | 11.6 | 1366×768 |
| B116XW02 V0 | AUO | 11.6 | 1366×768 |
| B116XW03 V0 | AUO | 11.6 | 1366×768 |
| B116XW03 V1 | AUO | 11.6 | 1366×768 |
| B116XW05 V004 | AUO | 11.6 | 1366×768 |
