| Onderdeel nummer | B116XAB01.2 |
| Merk | AUO |
| Maat | 11.6 |
| Sollicitatie | Laptop |
| Oplossing | 1366×768 |
| Samenstelling | Assembly , a-Si TF |
| Helderheid | |
| CR | 800:1 |
| Kleuren | 262K |
| Tegenlicht | WLED |
| Koppel | eDP |
| fabrikant | AUO |
| scherm grootte | 11.6 inch |
| pixel nummer | 1366(RGB)×768 (WXGA) 135PPI |
| actief gebied (mm) | 256.125 × 144 (H×V) |
| bezel gebied (mm) | - |
| luminantie | 220 cd/m² (Typ.) |
| kijk hoek | 85/85/85/85 (Typ.)(CR≥10) |
| goed zicht op | Symmetry |
| kleuren diepte | 262K 50% NTSC |
| omlijnde vorm | - |
| vernieuwingsfrequentie | 60Hz |
| signaal type | eDP (1 Lane) , eDP1.2 , 30 pins Connector |
| spanningsvoorziening | 3.3V (Typ.) |
| max. waarderingen | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| modelnaam | B116XAB01.2 (AUO125C) |
| scherm type | Assembly , a-Si TFT-LCD |
| regeling | RGB Vertical Stripe |
| overzicht (mm) | 287.7 × 185.6 × 4.2 (H×V×D) |
| behandeling | Glare (Haze 0%), Hard coating (7H) |
| contrast ratio | 800 : 1 (Typ.) (TM) |
| antwoord | 27 (Typ.)(Tr+Td) ms |
| werk modus | - |
| tegenlicht | WLED , 15K hours , With LED Driver |
| gebruikt voor | Laptop |
| touch screen | On-Cell Touch |
| B116XAN03.1 HW0A | AUO | 11.6 | 1366×768 |
| B116XAT03.1 | AUO | 11.6 | 1366×768 |
| B116XTN01.0 HW1A | AUO | 11.6 | 1366×768 |
| B116XTN02.3 HW0A | AUO | 11.6 | 1366×768 |
| B116XTN02.3 HW4A | AUO | 11.6 | 1366×768 |
| B116XTT01.0 | AUO | 11.6 | 1366×768 |
| B116XW01 V0 | AUO | 11.6 | 1366×768 |
| B116XW02 V0 | AUO | 11.6 | 1366×768 |
| B116XW05 V001 | AUO | 11.6 | 1366×768 |
| B116XW05 V004 | AUO | 11.6 | 1366×768 |
