| Onderdeel nummer | ATNA56WR06-0 |
| Merk | SAMSUNG |
| Maat | 15.6 |
| Sollicitatie | Laptop |
| Oplossing | 3840×2160 |
| Samenstelling | AM-OLED, OLED |
| Helderheid | |
| CR | 100000:1 |
| Kleuren | 1.06B |
| Tegenlicht | self |
| Koppel | eDP |
| paneel merk | SAMSUNG |
| paneelmodel | ATNA56WR06-0 |
| paneel grootte | 15.6" |
| paneel type | AM-OLED, OLED |
| oplossing | 3840(RGB)×2160, UHD, 283PPI |
| pixel formaat | RGB Vertical Stripe |
| weergavegebied | 344.218(W)×193.622(H) mm |
| omlijsting openen | - |
| omtrek grootte | 348.218(W)×215.572(H) ×2.2(D) mm |
| oppervlak | Glare (Haze 0%) |
| helderheid | 440 cd/m² (Typ.) |
| contrast ratio | 100000:1 (Typ.) (TM) |
| kijk hoek | 85/85/85/85 (Typ.)(CR≥10) |
| weergavemodus | - |
| beste zicht op | Symmetry |
| reactietijd | 1 (Typ.)(Tr+Tf) |
| kleuren weergeven | 1.06B 100% DCI-P3 |
| soort lamp | self |
| frequentie | 60Hz |
| touch screen | Without |
| vorm stijl | Slim (PCBA Flat, T≤3.2mm) |
| sollicitatie | Laptop |
| signaal interface | eDP (4 Lanes) , eDP1.4b , HBR2 (5.4G/lane) , 40 pins Connector |
| ingangsspanning | 3.3V (Typ.) |
| omgeving | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -40 ~ 85 °C |
