| Onderdeel nummer | AT070WSM-NW2 |
| Merk | BOE |
| Maat | 7.0 |
| Sollicitatie | Automotive Display |
| Oplossing | 1024×600 |
| Samenstelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 800:1 |
| Kleuren | 262K/16.7M |
| Tegenlicht | WLED |
| Koppel | |
| merk | BOE |
| model | AT070WSM-NW2 |
| diagonale maat | 7.0 inch |
| type | a-Si TFT-LCD, LCM |
| pixel formaat | 1024(RGB)×600 [WSVGA] 170PPI |
| configuratie | RGB Vertical Stripe |
| actief gebied | 154.214(H)×85.92(V) mm |
| omtrek afm. | - |
| luminantie | - |
| contrast ratio | 800:1 (Typ.) (TM) |
| richting bekijken | - |
| reactietijd | 25 (Typ.)(Tr+Tf) |
| kijk hoek | 80/80/60/70 (Typ.)(CR≥10) |
| bedrijfsmodus | TN, Normally White, Transmissive |
| ondersteunende kleur | 262K/16.7M 50% NTSC |
| lichtbron | WLED |
| gewicht | - |
| ontworpen voor | Automotive Display |
| frame rate | 60Hz |
| aanraakpaneel | Without |
| omgeving | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| AT070TN92 V.X | Innolux | 7.0 | 800×480 |
| B070ATN01.0 | AUO | 7.0 | 1024×600 |
| BP070HD1-100 | BOE | 7.0 | 720×1280 |
| C070FW03 V0 | AUO | 7.0 | 480×234 |
| C070VW03 V0 | AUO | 7.0 | 800×480 |
| CLAA070LC0ACW | CPT | 7.0 | 800×480 |
| CLAA070LC0CCW | CPT | 7.0 | 800×480 |
| LB070WQ6-TD01 | LG Display | 7.0 | 400×234 |
| LD070WS2-SL07 | LG Display | 7.0 | 1024×600 |
| ZJ070NA-01P | Innolux | 7.0 | 1024×600 |
