| Onderdeel nummer | AM800480R3TMQW-B2H |
| Merk | AMPIRE |
| Maat | 7.0 |
| Sollicitatie | Industrial |
| Oplossing | 800×480 |
| Samenstelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 400:1 |
| Kleuren | 262K |
| Tegenlicht | WLED |
| Koppel | LVDS |
| merk | AMPIRE |
| model | AM800480R3TMQW-B2H |
| diagonale maat | 7.0 inch |
| type | a-Si TFT-LCD, LCM |
| pixel formaat | 800(RGB)×480 [WVGA] 133PPI |
| configuratie | RGB Vertical Stripe |
| actief gebied | 152.4(H)×91.44(V) mm |
| omtrek afm. | - |
| luminantie | - |
| contrast ratio | 400:1 (Typ.) (TM) |
| richting bekijken | 6 o'clock |
| reactietijd | 5/11 (Typ.)(Tr/Td) |
| kijk hoek | 70/70/60/70 (Typ.)(CR≥10) |
| bedrijfsmodus | TN, Normally White, Transmissive |
| ondersteunende kleur | 262K 45% NTSC |
| lichtbron | WLED |
| gewicht | - |
| ontworpen voor | Industrial |
| frame rate | 60Hz |
| aanraakpaneel | Without |
| interface-type | LVDS (1 ch, 8-bit) , 20 pins Connector |
| stroomvoorziening | 3.3V (Typ.) |
| omgeving | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
