| Onderdeel nummer | AM1024600K7TMQW-T62H |
| Merk | AMPIRE |
| Maat | 7.0 |
| Sollicitatie | Industrial |
| Oplossing | 1024×600 |
| Samenstelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 700:1 |
| Kleuren | 262K/16.7M |
| Tegenlicht | WLED |
| Koppel | |
| paneel merk | AMPIRE |
| paneel grootte | 7.0" |
| oplossing | 1024(RGB)×600, WSVGA, 169PPI |
| weergavegebied | 153.6(W)×90(H) mm |
| helderheid | - |
| kijk hoek | 75/75/70/75 (Typ.)(CR≥10) |
| beste zicht op | - |
| kleuren weergeven | 262K/16.7M |
| frequentie | 60Hz |
| gewicht | - |
| paneelmodel | AM1024600K7TMQW-T62H |
| paneel type | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| omlijsting openen | - |
| contrast ratio | 700:1 (Typ.) (TM) |
| weergavemodus | TN, Normally White, Transmissive |
| reactietijd | 20/20 (Typ.)(Tr/Td) |
| soort lamp | WLED |
| touch screen | PCAP |
| sollicitatie | Industrial |
