| Onderdeel nummer | AM-800600MTMQW-50H |
| Merk | AMPIRE |
| Maat | 8.4 |
| Sollicitatie | Industrial Outdoor H |
| Oplossing | 800×600 |
| Samenstelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 600:1 |
| Kleuren | 262K/16.7M |
| Tegenlicht | 6S5P |
| Koppel | |
| paneel merk | AMPIRE |
| paneel grootte | 8.4" |
| oplossing | 800(RGB)×600, SVGA, 119PPI |
| weergavegebied | 170.4(W)×127.8(H) mm |
| omtrek grootte | 189.75(W)×149.4(H) ×5.3(D) mm |
| helderheid | 1000 cd/m² (Typ.) |
| kijk hoek | 75/75/60/70 (Typ.)(CR≥10) |
| beste zicht op | - |
| kleuren weergeven | 262K/16.7M |
| frequentie | 60Hz |
| gewicht | TBD |
| paneelmodel | AM-800600MTMQW-50H |
| paneel type | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| omlijsting openen | 173.4(W)×130.8(H) mm |
| oppervlak | - |
| contrast ratio | 600:1 (Typ.) (TM) |
| weergavemodus | TN, Normally White, Transmissive |
| reactietijd | 8 (Typ.)(Tr+Td) |
| soort lamp | 6S5P WLED , Without Driver |
| touch screen | Without |
| sollicitatie | Industrial Outdoor High Brightness |
