| Onderdeel nummer | AM-800480L6TZQW-TN0H-I |
| Merk | AMPIRE |
| Maat | 5.0 |
| Sollicitatie | Industrial |
| Oplossing | 800×480 |
| Samenstelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 250:1 |
| Kleuren | 16.7M |
| Tegenlicht | 3S4P |
| Koppel | Parallel |
| fabrikant | AMPIRE |
| modelnaam | AM-800480L6TZQW-TN0H-I |
| scherm grootte | 5.0 inch |
| scherm type | LCM, a-Si TFT-LCD |
| pixel nummer | 800(RGB)×480 (WVGA) 188PPI |
| regeling | RGB Vertical Stripe |
| actief gebied (mm) | 108 × 64.8 (H×V) |
| overzicht (mm) | 118.5 × 77.1 × 6.44 (H×V×D) |
| bezel gebied (mm) | 110.6 × 67.4 (H×V) |
| behandeling | - |
| luminantie | 500 cd/m² (Typ.) |
| contrast ratio | 250 : 1 (Typ.) (TM) |
| kijk hoek | 85/85/85/85 (Typ.)(CR≥10) |
| antwoord | 15/35 (Typ.)(Tr/Td) ms |
| goed zicht op | Symmetry |
| werk modus | Normally Black, Transmissive |
| kleuren diepte | 16.7M 52% NTSC |
| tegenlicht | 3S4P WLED , 30K hours , No Driver |
| massa | - |
| gebruikt voor | Industrial |
| vernieuwingsfrequentie | 60Hz |
| touch screen | PCAP |
| signaal type | Parallel RGB (1 ch, 8-bit) , FPC 45 pins |
| spanningsvoorziening | 3.3V (Typ.) |
| max. waarderingen | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| AMS495QA01 | Samsung | 5.0 | 960×544 |
| CLAF050LN41 TXX | CPT | 5.0 | 540×960 |
| EE050NA-04A | Innolux | 5.0 | 640×480 |
| LM050QC1T01 | SHARP | 5.0 | 320×240 |
| LMS501KF03 | Samsung | 5.0 | 480×800 |
| LQ050A5BS02 | SHARP | 5.0 | 320×234 |
| LQ050W1LA0A | SHARP | 5.0 | 1024×600 |
| LQ5AW136T | SHARP | 5.0 | 320×234 |
| LS050T1SX01 | SHARP | 5.0 | 1080×1920 |
| TFD50W72MS | TOSHIBA | 5.0 |
