| Onderdeel nummer | AM-800480D1TMQW-00H |
| Merk | AMPIRE |
| Maat | 8.0 |
| Sollicitatie | Industrial Automotiv |
| Oplossing | 800×480 |
| Samenstelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 500:1 |
| Kleuren | 262K/16.7M |
| Tegenlicht | WLED |
| Koppel | |
| merk | AMPIRE |
| model | AM-800480D1TMQW-00H |
| diagonale maat | 8.0 inch |
| type | a-Si TFT-LCD, LCM |
| pixel formaat | 800(RGB)×480 [WVGA] 116PPI |
| configuratie | RGB Vertical Stripe |
| actief gebied | 176.64(H)×99.36(V) mm |
| omtrek afm. | 192.8(H)×116.9(V) ×6.7(D) mm |
| bezel gebied | 180.1(H)×103.4(V) mm |
| behandeling | Antiglare |
| luminantie | 450 cd/m² (Typ.) |
| contrast ratio | 500:1 (Typ.) (TM) |
| richting bekijken | - |
| reactietijd | 10/15 (Typ.)(Tr/Td) |
| kijk hoek | 70/70/50/70 (Typ.)(CR≥10) |
| bedrijfsmodus | TN, Normally White, Transmissive |
| ondersteunende kleur | 262K/16.7M |
| lichtbron | WLED , 20K hours , W/O Driver |
| gewicht | 251g (Typ.) |
| ontworpen voor | Industrial Automotive Display |
| frame rate | 60Hz |
| aanraakpaneel | Without |
| Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -30 ~ 85 °C |
