| Onderdeel nummer | AM-800480BDTZQW-00H |
| Merk | AMPIRE |
| Maat | 4.3 |
| Sollicitatie | Industrial Automotiv |
| Oplossing | 800×480 |
| Samenstelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 700:1 |
| Kleuren | 16.2M |
| Tegenlicht | WLED |
| Koppel | Parallel |
| merk | AMPIRE |
| model | AM-800480BDTZQW-00H |
| diagonale maat | 4.3 inch |
| type | a-Si TFT-LCD, LCM |
| pixel formaat | 800(RGB)×480 [WVGA] 216PPI |
| configuratie | RGB Vertical Stripe |
| actief gebied | 95.04(H)×53.856(V) mm |
| omtrek afm. | 105.3(H)×67(V) mm |
| bezel gebied | 97.9(H)×56.7(V) mm |
| behandeling | - |
| luminantie | 500 cd/m² (Typ.) |
| contrast ratio | 700:1 (Typ.) (TM) |
| richting bekijken | Symmetry |
| reactietijd | 40 (Typ.)(Tr+Td) |
| kijk hoek | 80/80/80/80 (Typ.)(CR≥10) |
| bedrijfsmodus | Normally Black, Transmissive |
| ondersteunende kleur | 16.2M |
| lichtbron | WLED [6S2P] , 50K hours , W/O Driver |
| gewicht | - |
| ontworpen voor | Industrial Automotive Display |
| frame rate | 60Hz |
| aanraakpaneel | Without |
| interface-type | Parallel RGB (1 ch, 8-bit) , 40 pins FPC |
| stroomvoorziening | 3.3V (Typ.) |
| omgeving | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -30 ~ 85 °C |
